| PARAMETERS | MIN | TYP | MAX | UNITS | NOTES |
|---|---|---|---|---|---|
| Accuracy (combined non linearity, hysteresis, and repeatability) | -0.1 |
±0.1 |
0.1 |
%F.S. BFSL | I: High Accuracy Type |
| -0.25 | ±0.25 | 0.25 | %F.S. BFSL | II: Standard Type | |
| Zero Offset | -1 |
|
1 |
%SPAN | I: High Accuracy Type |
| -2 | 2 | %SPAN | II: Standard Type | ||
| Span | 98 |
|
102 |
mV | A: 0...100mV Output |
| 49 | 51 | mV | B: 0…50mV Output | ||
| Total Error Band | -1.5 | ±1.0 | 1 | %F.S | Over compensated temperature range |
| Isolation (Body to any Lead) | 100 | MΩ | |||
| Input Resistance | 4 | 8 | KΩ | ||
| Output Resistance | 3 | 6 | KΩ | ||
| Pressure Cycles | 1X107 | 0~FS Cycles | |||
| Proof Pressure | 2X | 20k psi | Rated | ||
| Burst Pressure | 5X | 20k psi | Rated | ||
| Long Term Stability (1 year) | -0.25 | ±0.25 | 0.25 | %F.S | |
| Compensated Temperature | 0 | 70 | °C | ||
| Operating Temperature | -40 | 125 | °C | ||
| Storage Temperature | -40 | 125 | °C | ||
| Rise Time (10% to 90%) | 1 | ms | |||
| Bandwidth | DC to 1KHz (typical) | ||||
| Pressure Port Material | 17-4PH+SST304 or 整体17-4PH | ||||
| Shock | 50g, 11msec Half Sine Shock per MIL-STD-202G, Method 213B, Condition A | ||||
| Vibration | ±20g, MIL-STD-810C, Procedure 514.2-2, Curve L | ||||
